UV Fused Silica Plano Convex Lenses

Telephone: +44 (0) 1268 728077

Stock Specification

Galvoptics are specialist suppliers of UV Fused Silica Plano Convex Stock optical lenses and also offer custom made UV fused silica Plano convex lenses.

We have a range of lenses available to purchase directly below using our online payment system, or alternatively we can create a custom built UV Fused Silica lens to match your specific requirements. Speak to a member of our team on 01268 728077.

MATERIAL	UV Grade Fused Silica	DIAMETER TOLERANCE	+ 0.0 / - 0.1mm
THICKNESS TOLERANCE	± 0.2mm	SURFACE QUALITY	40/20
CENTRATION	≤ 3 arc MINS	FOCAL LENGTH	± 2%

CUSTOM SIZES
DIMENSIONS	DIAMETERS 1mm TO > 300mm
COATINGS	PLEASE SEE BELOW

Part No.	Data Sheet	Description	Diameter (MM)	Focal Length	Thickness (MM)	Unit Price	QTY	BASKET	QUOTE
L40-004-005		UNCOATED UV FUSED SILICA	4.0	5.0	2.2	£39.50		BUY	ADD TO QUOTE
L40-004-005-UV		AR COATED R<0.5% @ 250~400NM	4.0	5.0	2.2	£47.50		BUY	ADD TO QUOTE
L40-010-012		UNCOATED UV FUSED SILICA	10.0	12.5	4.40	£39.50		BUY	ADD TO QUOTE
L40-010-012-UV		AR COATED R<0.5% @ 250~400NM	10.0	12.5	4.40	£47.50		BUY	ADD TO QUOTE
L40-010-025		UNCOATED UV FUSED SILICA	10.0	25.0	2.65	£39.50		BUY	ADD TO QUOTE
L40-010-025-UV		AR COATED R<0.5% @ 250~400NM	10.0	25.0	2.65	£45.00		BUY	ADD TO QUOTE
L40-010-050		UNCOATED UV FUSED SILICA	10.0	50.0	2.55	£39.50		BUY	ADD TO QUOTE
L40-012-025		UNCOATED UV FUSED SILICA	12.7	25.0	3.95	£41.50		BUY	ADD TO QUOTE
L40-012-050		UNCOATED UV FUSED SILICA	12.7	50.0	2.90	£41.50		BUY	ADD TO QUOTE
L40-012-100		UNCOATED UV FUSED SILICA	12.7	100.0	2.45	£41.50		BUY	ADD TO QUOTE
L40-025-050		UNCOATED UV FUSED SILICA	25.4	50.0	5.85	£43.50		BUY	ADD TO QUOTE
L40-025-100		UNCOATED UV FUSED SILICA	25.4	100.0	3.80	£43.50		BUY	ADD TO QUOTE
L40-025-250		UNCOATED UV FUSED SILICA	25.4	250.0	2.70	£43.50		BUY	ADD TO QUOTE

PART NO.	QTY	BASKET	QUOTE	Description	Diameter (MM)	Focal Length	Thickness (MM)	Unit Price	Data Sheet
L40-004-005		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	4.0	5.0	2.2	£39.50
L40-004-005-UV		BUY	ADD TO QUOTE	AR COATED R<0.5% @ 250~400NM	4.0	5.0	2.2	£47.50
L40-010-012		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	10.0	12.5	4.40	£39.50
L40-010-012-UV		BUY	ADD TO QUOTE	AR COATED R<0.5% @ 250~400NM	10.0	12.5	4.40	£47.50
L40-010-025		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	10.0	25.0	2.65	£39.50
L40-010-025-UV		BUY	ADD TO QUOTE	AR COATED R<0.5% @ 250~400NM	10.0	25.0	2.65	£45.00
L40-010-050		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	10.0	50.0	2.55	£39.50
L40-012-025		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	12.7	25.0	3.95	£41.50
L40-012-050		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	12.7	50.0	2.90	£41.50
L40-012-100		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	12.7	100.0	2.45	£41.50
L40-025-050		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	25.4	50.0	5.85	£43.50
L40-025-100		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	25.4	100.0	3.80	£43.50
L40-025-250		BUY	ADD TO QUOTE	UNCOATED UV FUSED SILICA	25.4	250.0	2.70	£43.50
